1
TVIFBR HD-TVI/AHD/HD-CVI/CVBS Fiber Extender with RS485
Thank you for your purchase of the TVIFBR fiber optical extender for analog cameras. This unit is designed to offer an affordable
way to send analog cameras signals up to 12 miles! The TVIFBR is based on digital uncompressed HD composite video
technologies which convert the camera signal to optical.
FEATURES
• Digital and non-compression coding technology
• Supports HD-TVI/AHD/HD-CVI/CVBS and RS485 data signal over fiber optical cable
• Single signal mode: 12.42 miles (20KM), Multiple signal mode: 1.24 miles (2KM)
• Also send up to 330’ (100M) via RG59/6U cable.
• Supports resolutions up to 5MP.
• Built-in 4kV surge protection in terminal blocks.
INSTALLATION VIEW
SPECIFICATIONS
Transmitter
Receiver
Video Format
HD-TVI/AHD/HDCVI/CVBS
Video Connector
BNC 50Mhz 75ohm
Fiber Port
FC, single fiber, single/multimode mode
Distance
0-12.42 miles (20KM)
Input/output Wavelength
TX1310, RX1550nm
TX1550,RX1310nm
Input/output Level
＞500mVP-P
1Vp-p
TX Input Return Loss
＞15dB
Input/output Impedance
75Ω
Rx up/down time
＜0.8ns
Rx Max. Jitter
＜0.2UI
Video Capture Resolution
10 bits
Baud Rate
1200-9600bps
BER
＜10
-9
Operation Mode
Half Duplex
Power
DC5V 1A (included)
DC5V 1A (included)
Power Consumption
≤5W
≤5W
Temperature
Operation: -4 to 167°F, Storage: -40 to 185°F, Humidity: up to 95%
Weight
0.4 lbs
0.4 lbs
UNIT VIEW
