Adding Rinse Aid Adding Detergent
Getting started with your new dishwasher.
9000633140 Rev A 3/11
Adjust Amount of Rinse Aid Dispensed
To Start the Dishwasher
1 - Always use Rinse Aid
2 - Use Auto Cycle
3 - Press Sanitize button
The sanitize feature is available only in the Heavy, Auto,
Normal and Half Load cycles. Press the “Sanitize” button
to activate the sanitation features during these cycles. The
sanitize LED will light when sanitation requirements are met.
For up to 45% dryer dishes:
Heavy Wash: Uses higher water temperature and pressure to remove baked-
on foods
Auto Wash: Reads the size and soil of each load, adjusting water and heat to
the ideal balance for optimum cleaning results
Normal Wash: Cleans normal loads with loosely attached, normal soiling
Delicate Wash*: Uses lower water temperature and pressure, safe for
delicate or heirloom dishware
Express Wash*: Cleans lightly soiled loads with reduced wash time
Half Load*: Can reduce energy and water consumption when washing small
loads that fill approximately half of the dishwasher’s capacity
Rinse & Hold*: Rinse the soil off of a partial load and hold the dishes until
you are ready to run a full load
* Available wash cycles vary by model
Cycle Descriptions
Call the toll free Customer Service number, 1-800-944-2904. Before calling, locate the
model number and serial number on the label on the inside of the dishwasher door.
To Contact Customer Service
Frequently Asked Questions
Dishes are not drying properly: Refer to section above.
Odor: Debris at the bottom of the dishwasher or in
the door seal can cause odor. Clean both according to
instructions in the Use and Care Manual.
Dishwasher still on after cycle ends: Default factory
settings have the dishwasher stay powered on after a
cycle ends. Customer must manually turn the dishwasher
off. Dishwasher must be powered on again in order to
start a new cycle.
For models with a display:
— With door closed, press the button.On/Off
— Press and hold down the button, then press >
and release the button. Now release the Start >
button.
— Press the button until the display shows “r:0...”. >
— Press the button to change the amount of rinse <
aid dispensed.
r:00 = rinse aid dispenser is OFF
r:03 = medium amount of rinse aid
r:06 = highest amount of rinse aid
— Press to save your setting.Start
For models without a display:
— With door closed, press the button.On/Off
— Press and hold down the > button, then press and
release the Start button. Now release the > button.
— Press the button until the “Clean” and “Refill >
Rinse Aid” LEDs are flashing.
— Press the button to change the amount of rinse <
aid dispensed.
0 LEDs flashing = rinse aid dispenser is OFF
1 LEDs flashing = lowest amount of rinse aid
2 LEDs flashing = medium amount of rinse aid
3 LEDs flashing = highest amount of rinse aid
— Press to save your setting.Start
— Use fresh powdered detergent or detergent tabs
for best results.
— 1 tablespoon will clean most loads
— 3 tablespoon max, do not overfill
— When using detergent tabs, lay them flat to avoid
contact with the cover.
To close the cover:
— Place finger on cover and slide
closed.
— Push rear end of cover down
firmly until it clicks.
To open the cover:
— Push the dark gray button and
cover will slide open.
— Press the button to turn dishwasher on.On/Off
— Press the arrow buttons to select desired cycle.Cycle Select
— Press to begin the cycle.Start
— Press and hold Start until the “Active”
LED or the wash cycle LED goes out
(model dependent).
— Wait about 1 minute while the dishwasher
drains.
— The “Clean” LED will illuminate when
done draining.
— Press the button. If you On/Off
choose to start a new cycle, turn the
unit on again and select a cycle.
To open the coverTo close the cover
Cancelling a cycle / Reset the dishwasher
— Rinse aid is necessary to improve drying results.
— Add rinse aid when the Rinse Aid indicator light
on the control panel illuminates.
— Lift tab to open the rinse aid reservoir and add
liquid rinse aid into the oval until it is full.
— Wipe up any excess rinse aid that may puddle.
3 Tbsp. Max.
2 Tbsp. (25ml)
1 Tbsp. (15ml)
ALWAYS READ YOUR USE AND CARE MANUAL FOR DETAILED INSTRUCTIONS
AND IMPORTANT SAFETY NOTICES.
If you need to cancel a cycle or the dishwasher control panel seems to not respond,
cancel or reset by following these steps.
13
2
4
