Asus TUF GAMING Z490-PLUS (WI-FI) Brugsanvisning
Her er Asus TUF GAMING Z490-PLUS (WI-FI) (Bundkort) brugervejledning. 68 sider på sprog Engelsk med en vægt på 4.9 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/68

Motherboard
TUF GAMING
Z490-PLUS (WI-FI)

Copyright © 2020 ASUSTeK COMPUTER INC. All Rights Reserved.
Offer to Provide Source Code of Certain Software
gpl@asus.com

Contents
Safety information iv ......................................................................................................
About this guide v ..........................................................................................................
TUF GAMING Z490-PLUS (WI-FI) specifications summary vi ....................................
Connectors with shared bandwidth x ..........................................................................
Package contents xi .......................................................................................................
Installation tools and components xii ..........................................................................
Chapter 1: Product Introduction
1.1 Before you proceed 1-1 ...................................................................................
1.2 Motherboard layout 1-2 ....................................................................................
Chapter 2: Basic Installation
2.1 Building your PC system 2-1 ...........................................................................
2.2 Motherboard rear and audio connections 2-16 .............................................
2.3 Starting up for the first time 2-20 ....................................................................
2.4 Turning off the computer 2-20 ........................................................................
Chapter 3: BIOS and RAID Support
3.1 Knowing BIOS 3-1 ............................................................................................
3.2 BIOS setup program 3-2 ..................................................................................
3.3 ASUS EZ Flash 3 3-3 ........................................................................................
3.4 ASUS CrashFree BIOS 3 3-4 ............................................................................
3.5 RAID configurations 3-5 ..................................................................................
Appendix
Notices A-1 ....................................................................................................................
ASUS contact information A-8 ......................................................................................

Safety information
Electrical safety
Operation safety

About this guide
How this guide is organized
• Chapter 1: Product Introduction
• Chapter 2: Basic Installation
• Chapter 3: BIOS and RAID Support
Where to find more information
1. ASUS website
2. Optional documentation
Conventions used in this guide
CAUTION:
IMPORTANT:
NOTE:

TUF GAMING Z490-PLUS (WI-FI) specifications summary
CPU
* Refer to www.asus.com for CPU support list.
** The support of these features depends on the CPU types.
Chipset
Memory
* 10th Gen Intel® Core i9/i7 CPUs support 2933/2800/2666/2400/2133 natively.
Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Graphics * Graphics specifications may vary between CPU types.
** Support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz. Please
refer to www.intel.com for any update.
Expansion Slots
Intel® 10th Gen Processors*
Intel® Z490 Chipset
* Support PCIe bifurcation for RAID on CPU function.
Multi-GPU Support
Storage
Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
Intel® Z490 Chipset
* M.2_1 shares bandwidth with SATA6G_2. When M.2_1 runs SATA mode,
SATA6G_2 will be disabled.
** M.2_2 shares bandwidth with SATA6G_56. When M.2_2 is occupied,
SATA6G_56 will be disabled.
Ethernet
Wireless & Bluetooth
Intel® Wi-Fi 6 AX201
* Bluetooth 5.1 function will be ready in Window 10 build 19041 or later.

TUF GAMING Z490-PLUS (WI-FI) specifications summary
USB
Rear USB (Total 6 ports)
Front USB (Total 6 ports)
Audio
Realtek ALC S1200A 7.1 Surround Sound High Definition Audio
CODEC*
Audio Features:
* Due to limitations in HDA bandwidth, 32-bit/192kHz is not supported for 7.1
Surround Sound audio.
Back Panel I/O Ports
Internal I/O Connectors
Fan and cooling-related
Power related
Storage related
USB

TUF GAMING Z490-PLUS (WI-FI) specifications summary
Internal I/O Connectors
Miscellaneous
Special Features
ASUS TUF PROTECTION
ASUS Q-Design
ASUS Thermal Solution
ASUS EZ DIY
AURA Sync
Software Features
ASUS Exclusive Software Features

TUF GAMING Z490-PLUS (WI-FI) specifications summary
Software Features
UEFI BIOS
BIOS
Manageability
Operating System
Form Factor

Package contents

Installation tools and components
Phillips (cross) screwdriver
PC chassis Power supply unit
Intel ®
LGA 1200 CPU Intel®
LGA 1200 compatible CPU Fan
DDR4 DIMM SATA hard disk drive
SATA optical disc drive (optional) Graphics card (optional)
M.2 SSD module (optional) 1 Bag of screws

Chapter 1
Product Introduction
Chapter 1: Product Introduction
1.1 Before you proceed

Chapter 1
1.2 Motherboard layout

Chapter 1
Layout contents Page

Chapter 1
1. CPU socket
LGA1200

TUF GAMING Z490-PLUS (WI-FI) 1-9
Chapter 1
4. Fan and Pump headers
The Fan and Pump headers allow you to connect fans or pumps to cool the system.
FAN PWM
FAN IN
FAN PWR
GND
GND
FAN PWR
FAN IN
FAN PWM
CPU_FAN
CPU_OPT
AIO_PUMP
CHA_FAN1
CHA_FAN2
CHA_FAN3
A B A
B
C
E
D
F
C
E F
D
• DO NOT forget to connect the fan cables to the fan headers. Insufficient air flow
inside the system may damage the motherboard components. These are not
jumpers! Do not place jumper caps on the fan headers!
• Ensure the cable is fully inserted into the header.
Header Max. Current Max. Power Default Speed Shared Control
CPU_FAN 1A 12W Q-Fan Controlled A
CPU_OPT 1A 12W Q-Fan Controlled A
CHA_FAN1 1A 12W Q-Fan Controlled -
CHA_FAN2 1A 12W Q-Fan Controlled -
CHA_FAN3 1A 12W Q-Fan Controlled -
AIO_PUMP 1A 12W Full-Speed

1-10 Chapter 1: Product Introduction
Chapter 1
5. Power connectors
These Power connectors allow you to connect your motherboard to a power supply.
The power supply plugs are designed to fit in only one orientation. Find the proper
orientation and push down firmly until the power supply plugs are fully inserted.
A
A
C
B
B
EATX12V_1EATX12V_2
+12V DC
+12V DC
+12V DC
+12V DC
GND
GND
GND
GND
EATXPWR
PIN 1
PIN 1
GND
+5 Volts
+5 Volts
+5 Volts
-5 Volts
GND
GND
GND
PSON#
GND
-12 Volts
+3 Volts
+3 Volts
+12 Volts
+12 Volts
+5V Standby
Power OK
GND
+5 Volts
GND
+5 Volts
GND
+3 Volts
+3 Volts
PIN 1
GND
GND
+12V DC
+12V DC
C
Ensure to connect the 8-pin power plug.
• For a fully configured system, we recommend that you use a power supply unit
(PSU) that complies with ATX 12V Specification 2.0 (or later version) and provides a
minimum power of 350 W.
• We recommend that you use a PSU with a higher power output when configuring a
system with more power-consuming devices. The system may become unstable or
may not boot up if the power is inadequate.
• If you want to use two or more high-end PCI Express p22-x16 cards, use a PSU with
1000W power or above to ensure the system stability.

TUF GAMING Z490-PLUS (WI-FI) 1-11
Chapter 1
6. M.2 slot
The M.2 slot allows you to install M.2 devices such as M.2 SSD modules.
M.2_1(SOCKET3)
M.2_2(SOCKET3)
A
B
A
B
• M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports SATA & PCIe 3.0 p23-x4
mode).
• M.2_2 slot (Key M), type 2242/2260/2280 (supports SATA & PCIe 3.0 p23-x4 mode).
• M.2_1 shares bandwidth with SATA6G_2. When M.2_1 runs SATA mode,
SATA6G_2 will be disabled.
• M.2_2 shares bandwidth with SATA6G_56. When M.2_2 is occupied, SATA6G_56
will be disabled.
• M.2 slots support IRST (Intel ® Rapid Storage Technology).
The M.2 SSD module is purchased separately.

Chapter 1
7. SATA 6Gb/s ports
B
A
C
B
A
C
[AHCI Mode]
[Intel RST Premium
With Intel Optane System Acceleration(RAID)]
RAID Configuration Guide
RAID Configuration Guide

TUF GAMING Z490-PLUS (WI-FI) 1-13
Chapter 1
8. USB 3.2 Gen 2 Front Panel connector
The USB 3.2 Gen 2 connector allows you to connect a USB 3.2 Gen 2 module for
additional USB 3.2 Gen 2 ports. The USB 3.2 Gen 2 connector provides data transfer
speeds of up to 10 Gb/s.
The USB 3.2 Gen 2 module is purchased separately.

1-14 Chapter 1: Product Introduction
Chapter 1
9. USB 3.2 Gen 1 header
The USB 3.2 Gen 1 header allows you to connect a USB 3.2 Gen 1 module for
additional USB 3.2 Gen 1 ports. The USB 3.2 Gen 1 header provides data transfer
speeds of up to 5 Gb/s.
U32G1_910
USB3+5V
IntA_P1_SSRX-
IntA_P1_SSRX+
GND
IntA_P1_SSTX-
IntA_P1_SSTX+
GND
IntA_P1_D-
IntA_P1_D+
GND
PIN 1
USB3+5V
IntA_P2_SSRX-
IntA_P2_SSRX+
GND
IntA_P2_SSTX-
IntA_P2_SSTX+
GND
IntA_P2_D-
IntA_P2_D+
A
The USB 3.2 Gen 1 module is purchased separately.
The plugged USB 3.2 Gen 1 device may run on xHCI or EHCI mode depending on the
operating system’s setting.

1-15
Chapter 1
10. USB 2.0 header
Connect the USB module cable to these connectors, then install the module to a slot
opening at the front of the system chassis. These USB headers comply with USB 2.0
specifications and support up to 480 Mbps connection speed.
A B
A
B
DO NOT connect a 1394 cable to the USB connectors. Doing so will damage the
motherboard!
The USB 2.0 module is purchased separately.

Chapter 1
11. Aura Addressable Gen2 header

Chapter 1
12. AURA RGB LED header

Chapter 1
13. Clear CMOS header
To erase the RTC RAM:
Del

Chapter 1
15. Front Panel Audio header
14. COM Port header

Chapter 1
16. System Panel header
• System Power LED header (PLED)
• Storage Device Activity LED header (HDD_LED)
• System Warning Speaker header (SPEAKER)
• Power Button/Soft-off Button header (PWRSW)
• Reset button header (RESET)
Chassis intrusion header (2-pin CHASSIS)

Chapter 1
17. Thunderbolt header
18. Q-LEDs

Chapter 1

Chapter 2
Basic Installation
2.1 Building your PC system
Chapter 2: Basic Installation
2.1.1 CPU installation

2-2
Chapter 2

Chapter 2
2.1.2 Cooling system installation
To install a CPU heatsink and fan assembly

TUF GAMING Z490-PLUS (WI-FI)
Chapter 2
2.1.3 DIMM installation
To remove a DIMM

Chapter 2
2.1.4 M.2 installation
For type 22110 M.2 on M.2_1 slot For type 2242 / 2260 / 2280 M.2 on
M.2_1 slot

Chapter 2
2.1.6 Motherboard installation

Chapter 2

Chapter 2
2.1.7 ATX power connection
OR AND

Chapter 2
2.1.10 Expansion card installation
To install PCIe x16 cards
To install PCIe p47-x1 cards

Chapter 2
2.2 Motherboard rear and audio connections
2.2.1 Rear I/O connection
* and ** : Refer to the tables on the next page for LAN port LEDs, and audio port definitions.
Rear panel connectors

Chapter 3
3.2 BIOS setup program
Entering BIOS at startup
Entering BIOS Setup after POST
Load Optimized
Defaults Exit <F5>
BIOS menu screen
EZ Mode Advanced Mode
Setup Mode Boot menu
